Key Features & Benefits
Floor-Mounted Ground Rail System -Modular rail-mounted platform enables expanded cutting lengths for oversized material processing and custom production requirements.
Open-Top Design -Simplifies crane, forklift, and side-loading operations while improving accessibility for large sheets and heavy plate.
High-Speed Fiber Laser Cutting -Delivers clean, precise cuts with rapid acceleration and excellent edge quality across mild steel, stainless steel, aluminum, and other metals.
Heavy-Duty Gantry Construction -Reinforced machine structure minimizes vibration and maintains cutting accuracy over long travel distances.
Expandable Table Configuration - Available in multiple widths and lengths to accommodate custom fabrication workflows and oversized applications.
Technical Specifications
Specification | Details |
Laser Source Power | Up to 40 kW |
Maximum Positioning Speed | 4700 in/min |
Positioning accuracy | ±0.001in/39.4” |
Repositioning Accuracy | ±0.0008in/39.4” |
Working Area | Widths: Up to 12ft Lengths: Up to 60ft+ |
| Rail System | Floor-Mounted Precision Ground Rails |
Options & Add‑Ons
Customize the Lightning to meet your workflow, production volume, and material needs:
- S&A water chiller (R134a refrigerant, dual-mode temperature control)
- Industrial dust collection systems with a high filtration rate
- Optional material handling upgrades (consult for details)
- Pipe attachment for cutting up to 12" round and 10" square
- 5-Axis Bevel Head
Built to Your Specs, Backed by Lonestar Quality
Every Lightning is built with your production environment in mind.
From table configuration to laser source selection, Lonestar Cutting Solutions collaborates closely with you to deliver a fiber laser cutting system tailored to your specific materials, throughput, and space requirements, all while maintaining the rugged quality and precision for which we’re known.
Financing Available
Need a fiber laser solution now but prefer flexible payment terms? We offer tailored financing options to help you get up and running—on your schedule and your budget.
Speak with a Lonestar Cutting Specialist Today
Looking to upgrade your shop’s cutting capabilities? Speak with a Lonestar Cutting Solutions rep today to see how the Lightning can fit into your operation.
