Key Features & Benefits
Industrial Motion System - Helical rack-and-pinion drives with air-assisted, anti-backlash transmissions provide ±0.007″ accuracy and ±0.002″ repeatability across every job.
Automated Torch Height Control - A dedicated leadscrew Z-axis paired with an integrated torch height controller ensures clean, consistent cuts—even on warped or uneven material.
Heavy-Duty Floor-Mounted Gantry - Constructed with 8″ × 8″ thick-wall steel tubing and mounted to a ground rail system, the gantry offers unmatched stability and precision, even on long runs.
Integrated Cable Track System - All wires, hoses, and cables are protected inside a fully enclosed track for safer operation and long-term reliability.
Technical Specifications
Feature | Specification |
Table Sizes | Widths: 5', 6', 8', 10', 12' |
Positioning Accuracy | ±0.007" |
Repeatability | ±0.002" |
Gantry Clearance | 8″ |
Max Traverse Speed | Up to 800 ipm. |
Available Torch Systems | Powermax 45, 65, 85, 105, 125, Max Pro 200, XPR 170-460-HPR800 |
Cutting Modes | Plasma, Oxy, Bevel, Rotary (round, square, rectangle, angle), drilling. |
Add-Ons & Custom Options
The Ranger III platform is fully modular and can be configured to meet your production goals.
- Automated 5-axis bevel cutting
- Drilling attachment (up to 2 tools)
- Rotary pipe & structural attachments (6″–24″ capacity)
- Multi-torch oxy-fuel support
Built to Your Specs
The Ranger III is engineered to scale with your operation.
Whether you're expanding an existing layout or building from scratch, our in-house team will work with you to configure the perfect system for your space, material volume, and processing requirements.
Financing Options Available
Need flexibility in your purchasing process? Ranger III models are eligible for custom payment plans through our financing partners. Get the cutting capabilities you need—on a timeline that works for you.
